    FUSION® SIGNATURE SERIES: 5 Channel 1600-Watt Marine Amplifier

    The Fusion® Signature Series 5-Channel amplifier is purpose-built to deliver robust power and performance for a full marine audio system. This highly efficient **Class-D amplifier** boasts a massive **1600-watt peak output**, providing **4 main channels** for speakers and a dedicated **Monoblock subwoofer channel**. Built on the **True-Marine™ design philosophy**, it features superior environmental protection, ensuring a signature performance season after season.


    CLASS-D POWER & SUPERIOR PROTECTION

    The 5-channel configuration is the ideal solution for powering a complete audio system (front, rear, and subwoofer) from a single amplifier, maximizing audio quality and efficiency.

    KEY AUDIO & DESIGN FEATURES

    • High Output Power: Delivers **80 W RMS x 4** (Main) and **250 W RMS x 1** (Subwoofer) at 4 ohms, providing ample power for crisp audio and deep bass.
    • Class-D Efficiency: Highly efficient design results in **lower battery drain** and a higher output than older Class-AB amplifiers.
    • Superior Protection: Features **conformal coated PCBs** (Printed Circuit Boards) and a rigid **aluminium alloy heat sink** for greater heat dissipation and protection against salt fog and humidity.
    • System Control: Includes built-in variable bass boost, a subsonic filter, and variable low/high pass crossover filters for superior system performance and protection.

    INSTALLATION AND CONNECTIVITY

    The 5-Channel amplifier is optimized for versatile, robust installation.

    • **Configuration:** Designed to power up to four pairs of speakers and one subwoofer.
    • **Operating Voltage:** Operates on **10.8–16 VDC**.
    • **Aesthetics:** Features a **polished stainless-steel mirror finish** control panel cover to conceal and protect connections while complementing any helm installation.

    Inverell Boating Centre Expert Note:

    The 5-Channel Signature Series amplifier (1600W Peak) is highly recommended for users building their first fully amplified system, as it powers both speakers and subwoofers from a single unit. Its 2-ohm stable design and comprehensive crossover controls ensure optimized acoustic performance when paired with Fusion DSP-enabled stereos (Apollo series).

    Specification in detail

    General & Physical


    PART NUMBER: 010-01968-00

    CHANNELS: 5 (4 Main + 1 Subwoofer)

    DIMENSIONS (HxWxD): 8.27″ x 11.81″ x 1.97″ (210 x 300 x 50 mm)

    WEIGHT: 7.94 lbs (3.6 kg)

    AMPLIFIER CLASS: Class D

    WARRANTY: 3 years

    Audio Performance


    PEAK POWER: 1600 W

    RMS POWER (4 Ω): Main: 80 W x 4 / Sub: 250 W x 1

    RMS POWER (2 Ω): Main: 130 W x 4 / Sub: 330 W x 1

    FREQUENCY RESPONSE: 10 Hz–50 kHz (Main Channels)

    SIGNAL PROCESSING: Variable High/Low Pass Filters, Subsonic Filter, Bass Boost

    Electrical & Connections


    OPERATING VOLTAGE: 10.8–16 VDC

    FUSE RATING: 2 x 40 A ATC blade-type (SAE J1171 compliant)

    CURRENT CONSUMPTION (MAX): 80 A

    INPUT IMPEDANCE: 4 kΩ nominal


    Inverell Boating Centre Technical Summary: The 5-Channel Signature Series amp is a powerful Class-D unit delivering 1600W peak power. It is designed to power an entire boat system (4 speakers + 1 subwoofer) using a single unit, maximizing efficiency (low battery drain) and protecting components via its conformal coated PCBs and advanced heat sink design.
